The low profile steel design automatic parking lock is a smart and reliable solution for securing private and managed parking spaces. Designed to prevent unauthorized vehicle access, this automatic parking lock integrates intelligent control systems with a durable steel structure, delivering both convenience and long-term performance.
Operating via remote control, Bluetooth app, or manual control, the automatic parking lock allows users to easily raise or lower the barrier when a vehicle approaches. Its low-profile design ensures smooth vehicle movement while maintaining a clean and modern appearance, making it ideal for residential communities, commercial parking lots, offices, and private garages.
Built for demanding outdoor environments, this smart parking lock combines safety, strength, and intelligent functionality to enhance parking space management efficiency.
Features
Low-Profile & Aesthetic Design
The flat, low-profile structure sits close to the ground and does not interfere with vehicle movement. This design improves driving comfort while enhancing the overall visual appearance of the parking area.Strong Steel Construction
Manufactured from high-strength carbon steel or manganese steel, the automatic parking lock offers excellent resistance to corrosion, rust, and impact. It is engineered to perform reliably in complex outdoor environments.Multiple Smart Control Options
Supports manual operation, remote control, electric lifting, and Bluetooth APP control. These flexible control methods provide a smarter, more convenient user experience for different application scenarios.Intelligent Safety Protection
Equipped with anti-pinch detection and anti-theft alarm functions, the parking lock ensures safe operation and effectively protects parking spaces from unauthorized use.Easy Installation & Maintenance
Suitable for concrete, asphalt, masonry, and other ground surfaces. The automatic parking lock is easy to install, with low maintenance requirements for long-term use.Energy-Saving Power Options
Optional solar-powered models are available, offering energy-efficient operation while supporting environmentally friendly parking solutions.
Product Specifications
| Parameter | Specification |
|---|---|
| Communication | 4G / Bluetooth / NB-IoT / LoRa |
| Operating Frequency | Full-band |
| Transmit Power | < 23 dBm |
| Receive Sensitivity | > -116 dBm |
| Detection Accuracy | > 99.9% |
| Detection Algorithm | Vector fusion + Baseline auto-following |
| Upgrade Method | Wired / Wireless (Bluetooth) |
| Power Supply | Solar-powered + Lead-acid battery (9AH/12V) |
| Standby Current | 200–300 µA |
| Motor Drive Type | Motor-driven, triggered by infrared / radar / geomagnetic sensors |
| Rust-Proof Rating | ST3 |
| Protection Rating | IP68 |
| Operating Temperature | -40℃ to +85℃ |
| Product Size | 1140mm × 580mm × 130mm |
| Max Barrier Height | Up to 200mm (self-adaptive to vehicle underbody height) |
| Barrier Rise/Fall Time | <10 seconds |
| Load Capacity | 8–10 tons |
| Net Weight | 51.2 kg |
| Lighting & Voice | LED warning lights & customizable voice broadcast |
| Video Capture (optional) | Auto-capture feature with >95.8% recognition rate |
| Status Monitoring | Low voltage, obstruction, fault, and tamper alarms |
Application scenarios
- Residential areas
- Commercial complexes,
- office buildings
- Hotel parking lots
- Office parks
- Personal parking spaces
- Public parking lot zoning
- management
